| Feature | Specification |
| Model / SKU | ANTO Wing (Lite / OEM) |
| Test Standard | EN ISO 11243:2016 (Class 25 kg) |
| Weight | 1.2 kg |
| Max. Load | 25 kg (max. 8 kg behind the rear axle) |
| Dimensions (L × W × H) | 530 mm × 220 mm × 420 mm |
| Wheel Sizes | 26″ to 36″ |
| Rear Axle Width | 135 mm – 190 mm |
Usage prohibition: The transport of persons, children, child seats, or animals is strictly prohibited. Do not make any structural changes to the product.
Weight distribution: From the maximum load of 25 kg, a maximum of 8 kg may be placed behind the rear axle. The permissible total weight of the bike (bike + rider + load) must not be exceeded.
Regulated tightening torques:
M6 screws: 6.8 Nm
M5 screws: 5.0 Nm
Frame mounting set: 4.3 Nm
Before each ride: Check the tight fit of all screws, secure the load, and ensure that taillights and reflectors are not covered.
Kronfeld Engineering
Owner: Karl Kronfeld
Main St. 9
16259 Beiersdorf-Freudenberg
Germany
Kontakt: info@anto.de | www.anto.de
Standard shipping times
Link to the complete shipping cost overview
For a step-by-step guide on using and assembling the anto loading area:
- Schau dir unseren YouTube-Kanal an
Scope of delivery
[1] 1× ANTO wing OEM
[2] 2× M6 × 14 mm screws (Torx T-30)
[3] 2× M5 × 14 mm screws (Torx T-25)
Required tools (not included):
Torx key T-25 (for M5 screws)
Torx key T-30 (for M6 screws)
Torque wrench (with T-25 / T-30 attachments)
Mounting options (The required tools depend on the chosen mounting kit):
Extensions 5, 7, 9
- Torx key T-30
- 10 mm wrench
Protective plate mounting kit
- Torx key T-25
- 8 mm wrench
Mounting kit
- Torx key T-25
- Hex key 4 mm
- Hex key 5 mm
- 8 mm wrench
- Metal saw
Does the Lite OEM loading area fit your bike?
Compatible with:
- Bicycles and e-bikes from 26-29 inches
- Wide rear axles like Boost / SuperBoost
- Mounting via fender and dropouts
- Gowind mountings 2x M6, optional M5 possible
- Mounting distance of dropouts (inside): 185 - 190 mm (± 10%)
More riding stability with luggage bags
The lower position of the pockets provides a lower center of gravity and more stability - even when heavily loaded.
Space behind the child seat
The compact design allows enough room for child seats and provides secure support for bags and accessories.
Ready for everyday life and tours
Whether shopping, commuting, or cycling - the Lite carrying surface holds what you need. Reliable, lightweight, and durable.
Take what would otherwise have to stay at home.
With the ANTO carrying surface, you can easily transport bulky, unusual, and large items, opening up possibilities that were previously unthinkable.
